Machining Center - Vertical

HEDELIUS C 60 / 2000

x-travel 2.000 mm
y-travel 620 mm
z-travel 520 mm
Control iTNC 530 Heidenhain
turning speed range - main spindle 30 - 12.000 min/-1
Torque 121 Nm
power capacity - main spindel 21 kW
tool taper SK 40
table surface area 2.500 x 600 mm
max. table load 2.000 kg
number of T-slots 5
T-slots 18 H8
number of toolpositions 30 pos.
tool taper SK 40
max. tool diameter 80 mm
max. tool-dia with free toolbox 125 mm
max. tool length 330 mm
max. tool weight 8,5 / 15 kg
change-time chip to chip 6,0 sec
change-time tool to tool 3,0 sec
total power requirement 25 kVA
weight of the machine ca. 10,5 t
dimensions of the machine ca. 8,0 x 4,0 x 3,5 m
Machining Center - Vertical
HEDELIUS - C 60 / 2000

- spindle runtime: ca. 12.045h

- Hofmann RT 320 NC round table
- centre height: 220 mm
- max. speed: 22 min-1
- Drive torque: 500 Nm
- Weight: 135kg

- Hofmann RE-40 / 220 tailstock
- taper: MK 3
- quill stroke: 40mm
- centre height: 220 mm

- incl. 2x chucks
- incl. spare pump
- incl. jaws

Credpfevnvz Iox Acujh
- NO clamping devices, NO tools
