Lathe

KAMI/SHEM DKM 500SC X 1000 mm

Top height 250 mm
Spindle bore 103 mm
Tip width 1000 mm
Circumference diameter over bed 500 mm
Lsdod I A Dhepfx Af Tohn
Circumference diameter in the crank 710 mm
Circumference diameter over support 300 mm
Speed range 9 - 1600 rpm (24 steps)
Spindle nose DIN 55029 Camlock D1-8
Range of longitudinal feeds 0,028 - 6,43 mm / rev; 93 steps
Range of feed rates 0,012 - 2,73 mm / rev. 93 steps
Metric threads 0.5 - 224 mm; 48 steps
Inch thread 72 - 1/8 gear / inch; 49 steps
Module thread 0.5 - 112 mm; 42 steps
Diametrical thread 56 - 1/4 DP; 42 steps
Quill ø 75 mm
Quilltravel 150 mm
Quill holder Morse cone 5
Motor power 7.5 kW
Weight 2,750.00 kg
Dimensions 2500 x 1100 x 1380 mm
