Wire-based Directed Energy Deposition

MELTIO M450

Dimensions (WxDxH): 560x600x1400 mm
Ledjqi A Hxjpfx Af Toru
Print Envelope (WxDxH): 145x168x390 mm
Weight: 250 kg
Laser Type: 6 x 200 W direct diode lasers
Laser Wavelength: 976 nm
Total Laser Power: 1200W
Power Input: 208/230 V single phase or 400 V three phase
Power Consumption: 2-5 kW peak depending on selected options
Process Control: Closed-loop, laser and wire modulation
Enclosure: Laser-safe, sealed, controlled atmosphere
Interface: USB, ethernet, wireless datalink
Cooling: Active water-cooled chiller included
Wire Materials: Compatible with a wide range of welding wires including stainless steels, mild steels, carbon steels, titanium alloys, inconel and tool steel.
Wire Feedstock: Diameter: 0.8-1.2 mm Spool Type: BS300

The machine was delivered from Meltio Spain in September 2022 in Refurbished condition and has only been used for printing the calibration cube. It has been equiped with new laser fibers with thermistors which check the temperature of the laser fibers and protect from overheating especially in long print jobs and up to date chamber door/safety glass. Hot wire option offers increased print speed with a programmable power supply that preheats the material before it enters the melt pool. The Dual Wire option allows for the fast and automatic switching of materials within a print without cross-contamination. Simplify3D licence (V4.1.2) is included.
