Universal lathe machine

Poreba TPK 80 x 3000

The PORĘBA TPK-80/3M universal lathe has been comprehensively rebuilt and modernized, has technical parameters in accordance with the technical and operational documentation DTR of a new machine, WOT technical acceptance conditions and the Polish Standard and also meets EU requirements.

The machine is covered by a full 12-month warranty on spare parts and electrical components.

Availability: delivery time 3,5 months, starting from the order

Technical data:

- distance between centers/turning length: 3000 mm
- turning diameter over bed: 800 mm
- turning diameter over support: 530 mm
- turning diameter in bridge recess: 1080 mm
- power on compound slide
- spindle bore diameter: 95 mm
- maximum workpiece weight between centers: 6,000 kg
- maximum workpiece weight between centers + 1 steady: 7,500 kg
- maximum workpiece weight between centers + 2 steadies: 9,000 kg
- number of spindle speeds: 21
- range of rotational speeds (rpm): 8 - 800
- number of feeds: 80
- range of feeds (mm/rev):
longitudinal: 0.1 – 12,8
transverse: 0.05 – 6,4
- engine power: 16/22 kW (1st gear / 2nd gear)
- overall dimensions:
total length: 5000 mm
width: 1800 mm
height: 1800 mm
total weight: 6200 kg

Standard equipment: tailstock, coolant pump, tool post, chuck cover

Additional equipment available at extra charge:

- 3- or 4-jaw chucks, various diameters and variants
Crsdpfofknw Rsx Acueh
- Digital readout on 2 axes with assembly and calibration
- Steady rest, 40-400 mm, with rollers
- Steady rest, 400-600 mm, with rollers
- MULTIFIX quick change tool post
