CNC lathe

Seiger SLZ 420E

Operating hours: 29,800 h
Control: Siemens 840D

Technical data:
Centre distance: 1,000 mm
Lodpfoxqp Ezsx Abtoah
Swing over bed: 430 mm
Swing over cross slide: 220 mm
Bed width: 350 mm
Turning tool cross-section (height x width): 20 x 20 mm
Spindle nose in accordance with DIN 55027: Size 6
Spindle diameter at front bearing: 110 mm
Spindle bore: 80 mm
Drive power 100% / 60% duty cycle: 9 / 11 kW
Speed range: 1 - 3,600 rpm
Rapid traverse X-axis: 10 m/min
Rapid traverse Z-axis: 7 m/min
Quill diameter: 70 mm
Quill stroke: 150 mm
Quill taper (internal): MK 5
Dimensions (LxWxH), approx.: 2,800 x 2,100 x 1,900 mm
Weight, approx.: 3,300 kg
