CNC drilling machine

Vitap Point 2

Number of independent vertical spindles: 8
Number of horizontal X-axis spindles: (2+2)
No. of horizontal Y-axis spindles: (1+1)
No. 1 blade for channel execution on the back of the cabinet: (ø 100 mm)
Max. panel thickness: 50 mm
Control: Full Parametric
Max panel weight: 25 kg
Max panel dimensions (see layout) : X ,Y 920, Z 50 mm
Min panel dimensions: X 270,Y 150 (70 op.), Z 12mm
Numbers of controlled axes: 3
Panel feed rate: 25m/min
Spindle rotation: 3600 rpm
Cjdpfx Aeuxmvzjcujrh
Operating pressure: 7 bar
Suction mouth diameter: ø 120 mm
Suction rate: (2000 mc/hour) - (30 m/s)
Max depth of all horizontal drilling in X and Y: 30 mm
Max drilling depth in vertical: 45 mm
Max horizontal drill bit diameter: 12 mm
Max vertical drill bit diameter: 35 mm
Motor: 1.5 kw
Dimensions: 2200x1350x1550 mm
Weight: kg 715
CE standards
