Single-shaft shredder

Zerma ZSS 850

Single-rotor shredder ZERMA ZSS 850-E 37 kW

Hopper opening (mm): 1340 x 840 mm
Usable cutting chamber: 690 x 730 mm
Rotor diameter x width (mm): Ø 387 x 850 mm
Rotor speed: 80 rpm
Rotor model: E
SEW oil-bath gearbox: Included
Number and size of knives: 40 / 34x34x22 mm
Knife holders with bolts: Included
Rcedjxtp Diepfx Ad Reh
Number of counter-knives: 1 row of 3
IE3 motor power: 37 kW
Screen perforations: > 40mm (to be specified)
Hydraulic screen opening: Included
Discharge height: 560 mm
Connected electrical power: 400 V +/- 5% / 50 Hz
Hydraulic pusher power: 3.6 kW
Hydraulic pusher with 2 speeds: Included
Adherent front plate (ram): Included
Air/Oil heat exchanger mounted on hydraulic tank
Overall length: 2085 mm - Overall width: 1940 mm - Height: 2435 mm
Approximate weight (kg): 4400 kg
Control cabinet with SIEMENS PLC and settings menus such as: Recipes, Maintenance, Alarms, etc.
Cable length to control cabinet: 5 meters
See technical datasheet and/or attached diagram for more details.
